Editable Mesh Tools
Editable mesh tools (listed in Table 4.3) are the polygon-editing tools found either through the shortcut menu (displayed in Figure 4.7) or the sub-object level of an object that has been collapsed to an editable mesh.
| Sub-Object Level | |||||
|---|---|---|---|---|---|
|
| |||||
| Mesh Tool | Vertex | Edge | Face | Polygon | Function |
|
| |||||
| Attach/Detach | ü | ü | Adds faces to/separates faces from object | ||
|
| |||||
| Extrude | ü | ü | ü | Creates new geometry from selected sub-object | |
|
| |||||
| Chamfer/Bevel | ü | ü | ü | ü | Rounds over selected sub-object—very useful. |
|
| |||||
| Create | ü | ü | ü | ü | Creates the desired element; also creates new shapes from multiple selected edges. |
|
| |||||
| Cut | ü | ü | ü | Allows you to arbitrarily cut new edges, faces, and polygons by merely “drawing” new edges—incredibly powerful. | |
|
| |||||
| Divide | ü | ü | ü | Allows you to choose the location of a new vertex (and subsequent faces and edges) by clicking along an edge | |
|
| |||||
| Weld/Break | ü | Combines/separates vertices | |||
|
| |||||
| Edges | ü | Provides edge visibility and direction control | |||
|
| |||||
| Normals | ü | Controls surface direction of faces | |||
|
| |||||
| Align Selected | ü | ü | ü | ü | Changes the orientation of selection |
|
| |||||
| Make Selected Planar | ü | ü | ü | ü | Aligns selected sub-object to common plane |
|
| |||||
| Hide Selected | ü | ü | ü | ü | Hides/unhides selection |
|
| |||||
)
FIGURE
4.7 The mesh modeling shortcut menu
